Hello everyone, I am working with the STM32H743BIT6 using the LTDC peripheral to drive an RGB display. The display I am using does not have HSYNC and VSYNC signals and operates only in DE (Data Enable) mode. I have attached the display datasheet for ...
Hi team, We have our own customized USBPD board (STM32L562CET6) which support both SPR(100W) and EPR(140W). SPR is working great, now we want to work on 140W using EPR mode. So that initially we have tried to enter EPR mode by following method #defi...
I am planning to do an aging test which need capture the voltage of a net, but i found STM32U585OIY6QTR report a value about 40 while the actual voltage of ADC channel is close to VREF.Then i write a simple ADC demo to verify ADC configuration, and r...
Hi everybody,I read 15 analog channels with DMA on my STM32f446. It works very well (It's tiggrered by TIM3 every 200ms).So I'd like to add Vbat. First, I've added it as the 16th channel of DMA, it works, but I saw the battery voltage decreases (arou...
Hi ST team,I am seeing what appears to be a silicon-level issue on STM32H563RGV6, revision X, related to the SWAP_BANK option byte.When SWAP_BANK is enabled, a USB OUT endpoint stops being re-armed during a flash mass erase of the inactive bank. The ...
Hi, I have an stm32g473 which use the clock of another system as external clock on PF0 / OSC_IN. This clock is them multiplied by 74 through the PLL. I need to synchronize my code with the external clock (i.e. wait for it to rise). What is the simp...
I was wondering if there is any possibility to change the NCS from NCS1_port2 to NCS2_port2 using the OTP registers on the STM32N6.I checked the registers but couldn’t find any option to adjust this. Maybe its not possible. Just to confirm my underst...
Dear ST,The STM32H5 overview page seems to display the wrong number(1) of CANFD controllers for STM32H5E4 in the line comparison table. The datasheet says it's 3, like for all the others in the STM32H5E/F lines.Also, I couldn't find anything in the...
Hello Forum,I want to use a Nucleo 64 STM32F401 Board to test I2C connection with an unknown master (reverse engineering).The Bus consits of 1 Master (unknown Controller) an 1 Slave (My STM32F40). The Master sends out a Read Request at Addr. 5 and t...
Hello,We programmed our STM32L011 microcontroller with firmware that enters STOP mode and waits for an interrupt.However, we accidentally disabled the interrupt on the PA4 line. As a result, the device now immediately enters STOP mode, and we are una...
