Resolved! NUCLEO-C5A3ZG STM32C5 QSPI Display Bring up Project
This project tests the STM32C5's XSPI capability to drive QSPI display using the NUCLEO-C5A3ZG M.2/SerialMem connector. GitHub - stm32-hotspot/STM32C5-M2-Serial-Mem-QSPI-Display · GitHub
STM32 MCUs Boards and hardware tools
Ask questions and find answers on STM32 hardware set-ups, including schematic-related challenges, debugging probes, power configurations, and more.
Forum Posts
Resolved! recommend a development kit with 3 independent DAC outputs exposed ?
Hello Everyone, I would like to get recommendations for STM32 development kits that have at least 3 DACs with their 3 independent outputs exposed, preferably a newer kit that can run an RTOS (not Linux). The faster the better. Thank you!
Resolved! Why is my HSE crystal not working on NUCLEO-L433RC-P board ?
I have fitted an 8MHz crystal with 8.2pF capacitors to the NUCLEO-L433RC-P development board, but it is not working.The software goes to an error handler when configuring the clocks, becuase of a time out iduring the function HAL_RCC_OscConfig (wait ...
Resolved! What software is needed to run Nucleo-L476RG with X-Nucleo-IKS01A3?
I have a Nucleo-L476RG and Nucleo-IKSO1A3. What software will I need to run examples on expansion bd sensors ?Anyone have old version of Unicleo-GUI ?version 1.10.XXX possibly? The new version does not show MEMSWhere can I find software that has the...
Resolved! STM32H7S78-DK – Factory Application and BSP Example Issue
Dear ST Support,I have two questions regarding the STM32H7S78-DK board.1. Is it possible to retrieve the original factory application that comes preloaded on the STM32H7S78-DK? I’ve already flashed my own project, but as expected, this process erase...
UART stops printing when using 25 MHz external clock on NUCLEO-H753ZI-$AT3
Hello,I am using a NUCLEO-STM32H753ZI-$AT3 development board.When I configure the MCU to use the internal clock (HSI), everything works correctly and my UART debug logs are printed normally.However, when I switch to using the external 25 MHz clock (H...
Resolved! Missing some schematic packs of the STM32F4DISCOVERY
Hello ST Community team, On the UM1472 Rev 8, the table 9 board revision history, it is mentioned that the MB997 initial rev is the B01 and the last rev is the F01. But on the https://www.st.com/en/evaluation-tools/stm32f4discovery.html#cad-resources...
Re: Riverdi_101 STM32H7: ST-Link can't connect to board
Split from old (apparently abandoned) thread: Riverdi_101 STM32H7: ST-Link can't connect to boardHi I am facing the same error is there any solution for this
Resolved! Using the Nucleo-F411 Board as an ST-LINK Programmer
Hello! I am a student studying STM32.First of all, thank you very much for your help. First of all, my main concern is that I would like to update the firmware on a board that has the G491RE mounted on it.However, we do not have an external ST-LINK, ...
Resolved! NUCLEO-U083RC
The controller on the board is erased via STM32CubeProgrammer.At the same time, the multimeter shows 1V on pin PC3 CN7:37 relative to GND CN7:8. How can this be?
Resolved! Can software developed for NUCLEO-F0 run on an F3 or F4 without modification?
Hello,I came across an old book in a bookstore that has some interesting bare metal C projects for a NUCLEO-F030. Other than setting the clock speed to 80 MHz and adjusting for some pin variance, will code written for it run on a NUCLEO-F3 or -F4?Th...
