Resolved! NUCLEO-C5A3ZG STM32C5 QSPI Display Bring up Project
This project tests the STM32C5's XSPI capability to drive QSPI display using the NUCLEO-C5A3ZG M.2/SerialMem connector. GitHub - stm32-hotspot/STM32C5-M2-Serial-Mem-QSPI-Display · GitHub
STM32 MCUs Boards and hardware tools
Ask questions and find answers on STM32 hardware set-ups, including schematic-related challenges, debugging probes, power configurations, and more.
Forum Posts
Resolved! I cant connect to my EVALKITST8500-1 using Smartgrid LabTool V4.4.
The power cable and the USB cable for kit interface are connected properly.When I connect the interface cable as per the the quick start guide, the LabTool does not recognize any port. If I go to settings - port: I can find no port to chooseIf I go t...
Resolved! where to download CAD ZIP files for STM32H753I-EVAL2 board and Nucleo-H753ZI board???
Where to download CAD ZIP files for STM32H753I-EVAL2 board and Nucleo-H753ZI board???I can't find ZIP files in https://www.st.com/en/evaluation-tools/nucleo-h753zi.html#cad-resourcesI can't find ZIP files in https://www.st.com/en/evaluation-tools/st...
Power Module On on NUCLEO-H723ZG
Hi i want to enable Power module (Generally PWR EN) on which bus i can enable this bit in can of NUCLEO-H723ZGas for reference manual is used RM0468 Also if you find this please give me link to that data sheet and secion number as i can not find it i...
STM32F103C6T6A Development Board
Is there a development board for specifically STM32F103C6T6A chip, (LQFP 48). I only see 64 pin version on this site. If there is no such board, what are my options? I specifically want to avoid using bootleg versions of the chip, so want to avoid us...
ST-LINK V2 cannot detect STM32F103 on custom board via SWD
Hello everyone,I am working on a custom board using an STM32F103 (LQFP48) and connecting it via ST-LINK V2 using the SWD interface.However, when I try to connect, STM32CubeProgrammer reports:Error: No STM32 target found!The log shows that the ST-LINK...
Resolved! Using VCP on Nucleo-H7S3L8
Split from: Nucleo-H7S3L8 Board in Arduino IDE - this is a new question.Hi @Andrew Neil Trying to send text via USART3 (which is linked to the virtual com ST LINK USB, correct?) and show it with Putty. But as I see the USART3 in the MX is disabled ...
ST-LINK V3SET fails to detect STM32F411E-DISCO
Hello,Until yesterday I was able to connect my ST-LINK V3SET via SWD to my STM32F411E-DISCO board without any problems. My setup is the STM32 extension for VSCode, where I debug using the STM32CubeProgrammer CLI. Everything was working fine, but now ...
Difference between F446RE & F446ZE Nucleo
Hello... can anyone advise on the difference between F446RE and F446ZE? i just found out the USART to USB VCP was shifted to USART3 instead of USART2 in the new ZE. Can anyone advise on any other difference?
Resolved! PWR_CSR2_USB33RDY flag is not set in Nucleo-H7S3L8
I was able to get CDC_Standalone in STM32CubeH7RS running on Nucleo-H7S3L8.Next, I am trying to get USB FS CDC running based on the Templates_board project.First, I need to modify the .ioc file to display the COM port in the Windows Device Manager. H...
Which STM MCU and board do I use for my project?
HI Team,I am Pranathi, I am looking for a board and MCU chip for my project, I want to implement a CAN protocol between 2 STM32 boards with FSM (finite state machine) and RTOS included in it. Additionally I will be using a sesnor and an actuator on e...
