Others: hardware and software

I need to Pspice Model of ST1CC40. Could you help me?

I need this Pspice model to test the performance of this chip on an array of LEDs

Hi every time i try to build the program i have this error #error cpstm8 C:\Program Files (x86)\COSMIC\FSE_Compilers\CXSTM8\HSTM8\mods0.h:1 FlexLM Invalid host.

Got the following error when I tried to click on the .bat file generated by eDesignSuite. No value found for registry key: "HKEY_CLASSES_ROOT\SIMetrixSchematic\shell\open with STMicroelectronics eDSim Electrical simulator\command"

Hi I am trying to establish a communicate between STM8 and BL0940 calibration free IC and I want to read registers of BL0940, but unable to get success in that Please help me out to solve this.

I am using STM8S103F3P

ST1S14PHR buck 24V/1A with an input voltage 27 to 36V

I was simulating this design, and the eDesingSuite gave me a solution (attached image) that I tested. When I tested the design, I found that I have a 4Vpp ripple, so that's not matching with the eDesingSuite simulation.Does any tell me what could be ...

Device not send the join uplink when change the keys from OTAA to ABP

Hi,​​​I have used Stm8 controller and I have change the keys from OTAA to ABP. In OTAA mode I have get the joining uplink(first uplink) but i didn't get the joining uplink in ABP.​ When I reset the device after get the second uplink in the network se...

Low profile, vertical Board to Board connector for multiple STM32 daughterboards

I have a main board with an STM32 uC which communicate with multiple STM32 uC daugtherboards over SPI. I currently use standard male pin headers on the top of the main board, and female socket connectors on the bottom of each daughterboard. The re...
